Network Analyzers (2-55 Harmonic Measurement, RS-485 Communication, Custom LCD)

₨84,500.00

Description

Parameter	Measured Values
Total Harmonics Distorition	THD-V, THD-I
Voltage Harmonics	Up to 55st harmonics (L-N and L-L]
Current Harmonics	Up to 55st harmonics
Active Power	P1, P2, P3, ΣP
Reactive Power	Q1, Q2, Q3, ΣQ
Q	S1, S2, S3, ΣS
Power Factor	True PF, cos φ (of each phase)
Voltage	phase-to-phase
	phase-to-neutral
	(min, max & average values are saved)
Current	I1, I2, I3, ΣI (min, max & demand are saved)
Frequency	F1, F2 ,F3 (min, max & average)
Energy	∑kWh (import & export)
	∑kVARh (inductive & Capacitive)
Relay Output	2 Relay outputs (adjustable), 1 digital input
Irregularties	voltage and current İmplances
Screen	71.5 X 61.5 Custom Design Glass LCD.
Communication	RS485 Modbus RTU
Event logs	High voltage, low voltage, power interruption, Voltage and current implances, high current, THD-V & THD-I limits
Real time Clock	Date and time can be set
Memory	You can delete energy values, demands records and event logs.
Password	Menu is password protected
